12.1 Inch Display Screen Touch Bonding

12.1 inch display screen touch bonding 1. Product Introduction of 12.1 inch display screen touch bonding We supply 12.1 inch display screen touch bonding. We devoted ourselves to touch industry many years, covering most of Europe and the American market. We are expecting become your long team...
Chat Now
Product Details

12.1 inch display screen touch bonding


1. Product Introduction of 12.1 inch display screen touch bonding

We supply 12.1 inch display screen touch bonding. We devoted ourselves to touch industry many years, covering most of Europe and the American market. We are expecting become your long team partner in China.


2. Product description of 12.1 inch display screen touch bonding

Specification//Technical parameters

Screen size/ Type

12.1  inch display screen touch bonding

Model number

EG-12.1-A-0403V1/EG-12.1-A-1610V1

Structure

Glass+Glass

Resolution

4096*4096

Ratio aspect

4:3/16:10

Interface type

USB, RS232, I2C

IC controller

EETI,  LG

Sensor

DITO

Outline dimension(CG/mm)

280*218.5(Customization  is available)

Viewing area(CG/mm)

246*184.5mm

/262.2*164.4mm

Cover glass thickness

/mm

2mm(Max  12mm

Optional)

Sensor glass thickness

/mm

0.55mm

Total thickness/mm

2.75mm

Dimension tolerance

±0.2mm

Color

Black,transparent,  white,silver for

any  colors optional


Surface hardness

>6H

Application

Industrial,military,

medical,banking,

consumer,aviation,

Education,security


Operating system

Win  XP/7/8/10,

Android,  Linux, Mac

Product characteristics

Operation Temperature

-10°C~+60°C  at Min 20% to Max 90%RH

Storage Temperature

-15°C~+65°C  at Min 20% to Max 90%RH

Electrostatic Discharge
 (non operation)

Contact: ±  4kv, 3 times/1 point, 1 time/1 sec,
Total 3 point

Air: ±  8kv, 3 times/1 point, 1 time/1 sec,
Total 3 point

Optical Property

Transmittance

>85%

Haze

3%↓

Electrical Characteristics(TA=40 to  +70°C Regin=5.0V unless otherwise specified)

Interface to Host / Master

USB,  4 wire, 2.0 Full speed

Supply Voltage

USB  5VDC

Oscillator Frequency

12MHz

Support Points

Multi-touch,  Single touch

Min. Report Rate

100points  /sec (Target, Need formal test report)




3. Product feature and application of 12.1 inch display screen touch bonding

Our Advantages



Why Choose Ever Glory?

Ø High quality Control with CE,ROHS,ISO and so on approved.

Ø Precise and advanced equipments

Ø More than 10 years of industry experience and involved main markets all over the world


Product feature

image004 - 副本.jpg



Application

TouchMonitor,Industrialautomation, Medical Surveillance, Marine devices, ATM machine, POSterminal(Retail/Restaurant/Quick service/Bars/Information), Metro ticket machine, Navigation car automotive system.

image007 - 副本.jpg


Production details

Our Touch display module consists of Touch panel+ LCD module full bonding.

4. Product qualification of 12.1 inch display screen touch bonding

There are 9 patents and ROHS, ISO, CE & FCC certificates has been obtained so far.

image013 - 副本.jpg


5. Shipping, Packing and Payment



6. Our service:

image018 - 副本.jpg


7. Customer visit or trade show

image020 - 副本.jpg


8. FAQ of 12.1 inch display screen touch bonding

Q1: If i will need to stay in your place for few days, is that possible to book the hotel for me?

A: It’s always my pleasure, hotel booking service is available.


Q2: How does your factory do regarding quality control?
A: Quality is our orientation. Our supervision department control the quality from raw material to finished product step by step carefully, make sure everything perfect before shipment.


9. Company introduction

image021 - 副本.jpg



10. Production workshop

Production process flow:




11. Contact information:
